Helium Leak test system

Engineered for Advanced Micro-Leak Detection & Integrity Validation

In high-precision manufacturing, a single microscopic leak can compromise system safety, lifecycle efficiency, and regulatory compliance. Engineered for the Aerospace, Defense, Automotive, EV Systems, and High-Precision Manufacturing sectors, Hawkstein Helium Leak Testing Systems deliver advanced, high-sensitivity solutions designed to isolate micro to macro defects across critical components.

Utilizing state-of-the-art Helium Mass Spectrometry and vacuum decay methodologies, Hawkstein systems ensure zero-defect quality, tracing the most elusive leaks to guarantee compliance with stringent global leak integrity standards.

Technical Specifications

Feature	Professional Benchmark
Leak Detection Technologies	Helium Mass Spectrometry, Helium Sniffer, Vacuum Decay
System Footprint / Dimensions	1800mm (W) × 2000mm (D) × 1600mm (H) — Heavy-duty, ergonomic floor-standing industrial enclosure
Test Media	Helium (He), Nitrogen (N2) background flushing, Compressed Air
Detection Sensitivity	Ultra-fine trace leaks down to 10^{-9}mbar}\ L/s with integrated helium mass spectrometer
Test Methods Supported	Vacuum Chamber Method (Inside-Out), Sniffer Method (Outside-In), Vacuum Decay
Automation & Control	PLC-Based Control with High-Resolution HMI & Automated Data Logging
System Integration	Inline / Offline / Robotic Testing Compatibility for Industry 4.0 production lines
Construction	Industrial-Grade, Heavy-Duty, Corrosion-Resistant Enclosure
Customization	Custom-engineered vacuum fixtures and tooling tailored to component geometry

Why Choose Hawkstein Helium Leak Testing Technology?

Ultra-Fine Tracer Sensitivity: Engineered specifically to leverage the small-molecule "search" characteristics of Helium gas, capturing microscopic structural flaws that pressure decay methods miss entirely.
Industrial-Grade Architecture: Housed in our standard 1800mm × 2000mm × 1600mm stable, heavy-duty industrial enclosure built to withstand continuous, high-throughput manufacturing floor environments.
PLC-Driven Traceability: Advanced PLC logic handles evacuation, helium charge, fine-leak sensing, and venting sequences automatically, logging unalterable test logs for regulatory tracking.

Strategic Applications

Aerospace & Defense: Validation of critical high-pressure fuel systems, emergency oxygen lines, cryo-valves, and strategic defense pressure components.
Automotive & EV Mobility: High-precision trace testing for EV battery enclosures, cooling plates, air conditioning components, and fuel delivery manifolds.
Industrial Manufacturing & Medical Devices: Leak integrity assurance for specialized high-pressure process valves, heat exchangers, and hermetically sealed medical or life-support apparatus.

FAQs

Because Helium molecules are exceptionally small, they can escape standard industrial seals. Hawkstein systems utilize ultra-precise, high-vacuum chambers, hard stainless steel piping, and specialized compound dynamic seals to completely isolate the tracer gas and direct it straight to the spectrometer.

Yes. To achieve high sensitivity (10^{-9} mbar L/s}), the component must be tightly integrated into a vacuum circuit. We custom-engineer fixture-based tooling for various component geometries to ensure repeatable, automated sealing.
